EPS Sandwich Panel Roll Forming Machine Production Line
Revolutionizing Building Materials Production with EPS Sandwich Panel Roll Forming Machine Production Line
The construction industry continues to evolve with increasing demands for energy-efficient, durable, and cost-effective building materials. EPS sandwich panels have emerged as a preferred solution for modern construction projects, offering exceptional thermal insulation, structural strength, and installation efficiency. As a specialized manufacturer of cold roll forming equipment, we proudly introduce our advanced EPS Sandwich Panel Roll Forming Machine Production Line, a complete manufacturing solution engineered to produce high-quality insulated panels with remarkable precision and efficiency. This sophisticated EPS Sandwich Panel Roll Forming Machine Production Line represents our commitment to delivering innovative technology that meets the rigorous demands of the modern construction industry.
More parameters
| Product Name | EPS Sandwich Panel Roll Forming Machine Production Line |
| Total power of equipment | 40 kw |
| Operating voltage | 380 V（Customizable） |
| Produce speed | 0-6 m/min |
| Electrical control system | The PLC is operated by Delta, featuring a 7-inch color touchscreen; the frequency converter is Delta; the counter is Omron; the motor is Shanghai Lichao; and the glue pump is Shanghai Shuangzhou. |
| Color steel sheet thickness | 0.2-0.6mm |
| Roll forming machine part | Forming row: 16 rows; Shaft diameter: ф70 mm; Motor: 5.5kw |
| Product thickness |
EPS: 50-250mm Rock wool: 50-100mm |
| Composite host section | 52-pass roll forming process (roller diameter 180mm) |
| Feeding width | 1000mm/1200mm |
| Production line size | Composite main unit length: 9 meters; Feeding mechanism: 6.5 meters; Cutting machine: 4 meters (recessed front cutting); Feeding section: 6-meter conveyor belt; Total equipment length: 38 meters; Total equipment width: 2.2 meters; Total equipment height: 2.4 meters |
| Equipment operating area | 45m*7m*4 m |
| Material and thickness | a. EPS foam thickness: 30-250mm b. Rock wool: 50-100mm |
| Glue pump dispensing volume | 0~0.4 kg per dose |
| Glue (black glue: white glue) | 1:1 |
| Glue application speed | 80 times/minute |
| Cutting system |
Weight：~ 1.0 t Drive motor：1.5kw×2 Sandwich Panel length: >= 1500mm |
Production Process
The production process of our EPS Sandwich Panel Roll Forming Machine Production Line incorporates a fully automated, streamlined workflow that ensures consistent quality from raw materials to finished products. The operation begins with automatic decoiling systems that feed steel coils into the production line with precise tension control. The material then proceeds through the precision roll forming section, where computer-engineered rollers gradually shape the metal into perfect panel profiles. The shaped metal sheets then advance to the feeding station where EPS core materials are precisely positioned. The heart of the EPS Sandwich Panel Roll Forming Machine Production Line is the composite panel formation section, where the metal sheets and insulation core are bonded under controlled pressure and temperature. Following this, an automated cutting system sections the continuous panels to required lengths, while the receiving system organizes the finished products for convenient handling and shipment.
What truly distinguishes our EPS Sandwich Panel Roll Forming Machine Production Line is its exceptional production efficiency and consistent output quality. The equipment maintains perfect synchronization between all operational stages, ensuring uniform panel thickness and superior bonding quality throughout the production process. The advanced control system, featuring sophisticated PLC technology and user-friendly interface, allows operators to monitor and adjust all production parameters with precision. This ensures that every panel produced by the EPS Sandwich Panel Roll Forming Machine Production Line meets the highest industry standards for dimensional accuracy and performance characteristics.
Beyond the advanced machinery, we provide comprehensive technical support to ensure optimal performance throughout the equipment's operational lifecycle. Our remote service program includes real-time video guidance from experienced engineers, who can assist with machine installation, operational training, maintenance procedures, and troubleshooting through digital platforms. This support system ensures that your EPS Sandwich Panel Roll Forming Machine Production Line maintains peak performance while minimizing potential downtime.
Application scenarios
Our photos with our customers
Our Certificate
FAQ
Q: Are you a trading company or a factory?
A: We are a factory with a professional production team and service consciousness, just for exporting various types of cold roll forming machines.
Q: Can a machine produce only one style of panel profile?
A: Not complete. Suitable for a EPS Sandwich Panel Roll Forming Machine Production Line. It can produce more than 3 panels.
Q: How long does it take to manufacture the machine?
A: In general, the EPS Sandwich Panel Roll Forming Machine Production Line be completed in 30 to 45 business days. But if you need machines urgently, we can save you time.
Q: Is there quality control when producing the production line?
A: Yes, we have a team that is responsible for quality control, including the laying of raw materials, processing rolls and other parts, processing, assembly, testing, and packaging on the roll surface and shaft.
Q: What can you do if the machine breaks?
A: Our machine is warranted for 24 months. If the damaged part cannot be repaired, we can send a new part to replace the damaged part, but you will need to pay the courier fee yourself. If the warranty period is exceeded, we can resolve the issue through negotiation, and we provide technical support for the entire life cycle of the device.
